IHC-ISH
BIOCARE ONCORE Pro
Reference ITEM: ONCPR00001
Pro Performance For Your Laboratory
The ONCORE Pro® Automated Slide Staining System now performs fully automated ISH so you can run your FISH probes and CISH probes with full automation and the convenience of a compact bench-top system.
The in vitro diagnostic (IVD) labeled the ONCORE Pro Automated Slide Staining System a compact powerhouse for any clinical laboratory. ONCORE Pro opens a world of possibilities to perform IHC, ISH, FISH, and CISH in a single compact benchtop platform. The ONCORE Pro processes up to 36 slides in a single run, with the ability to perform independent protocols at each slide position for high-throughput slide processing.
This Stainer machine’s slide processing is facilitated by unique reaction modules that enclose slides between a heated platform and a novel reagent containment chamber. Reagents are dispensed onto slides through a port attached to each chamber, allowing for minimal reagent usage and waste production. These unique chambers provide gentle agitation to enhance incubation throughout the staining procedure, maximizing staining intensity while minimizing background. The ONCORE Pro also accommodates simultaneous Multiplex IHC, allowing fast and efficient processing of multiple IHC markers on a single slide.
ONCORE Pro fully automates the staining process utilizing advanced online antigen retrieval technology, pre-optimized reagents, and ready to use antibodies to enhance laboratory workflow, increase laboratory efficiency, and reduce hands-on processing time. Solve modern-day challenges facing your laboratory now and in the future with the advanced automated slide staining machine, ONCORE Pro.
- Fully Automated Online Antigen Retrieval (HIER)
- Ready to Use Single and Multiplex IHC Staining Protocols
- Conserve Bench Space with Compact Footprint
- Intuitive Software for Ease of Use & Protocol Programming
- 2-D Matrix Labels Virtually Eliminate Patient ID Errors
- Waste Separation Reduces Hazardous Waste & Disposal Costs
System Specifications
Slide Capacity | 36 slides |
Reagent Rack | One reagent rack holds a maximum of 40 reagent vials |
Antigen Retrieval Temperature Range | Room temperature to 103°C; Max 110°C at Sea Level |
Multi-Dispensing Syringe Capacity | 5mL |
Dispense Volume | Antibody: 130uL; Reagent: 65 minimum – 400 μl maximum |
DePar Dispense Volume | DS1 – 240uL and DS2 – 200uL |
Carboys & Waste | Wash Buffer (2L), Hazardous (4L) and Non-Hazardous Waste (4L) |
Unit Control | One Instrument Per Computer |
Electrical Requirements | 120V 110/120V (±10%) 60Hz (±2Hz) 850 watts 220V 220/240V (±10%) 50Hz (±2Hz) 850 watts |
Voltage Tolerance | 100 to 240 AC |
Noise Rating | Minimum Operating Noise 47.0 dBA, Maximum Operating Noise 69.6 dBA |
Reports | Slide Barcode, Patient Information, Staining Runs |
LIS | HL7 Server Connection and MSSQL Database Connection |
Products Catalog
https://www.youtube.com/watch?v=rzEQqu9msOw
Operating Manual
